Day7: Kubernetes Backup and Restore

Backup Candidates

1. Resource Configuration.

2. etcd Cluster.

3. Persistent volumes.

Resource Configuration

We deploy number of application in K8s using Pods, Deployments, and a Service definition file.

• Approach 1: Create a manifest file using a Declarative approach It’s a preferred approach and can be stored it in the source code repository. Even if we lost the entire cluster, we can reapply the manifest file from git.

•      $ kubectl apply -f deployment.yaml
       $ kubectl apply -f service.yaml


  Approach 2: Clearing the Kube-apiserver

  - Use kubectl or access kube-apiserver directly, save all objects created on the cluster as a copy.

•       $ kubectl get all --all-namespaces -o yaml > all-deploy-services.yaml # add commands in backup scripts


Backup Tool:

• Use ARK(VELERO) tool to take a backup of the Kubernetes cluster by the kube-apiserver.

etcd Cluster

• it stores the state of the Kubernetes cluster, node information, etc.

• Approach 1: While configuring etcd, we specify the location where data can be stored in a particular directory.

$ etcd.service

Using etcdctl (Snapshot-based Backup)

1. Backup of the etcd database using the snapshot save command.

etcdctl --endpoints=https://[127.0.0.1]:2379 \
--cacert=/etc/kubernetes/pki/etcd/ca.crt \
--cert=/etc/kubernetes/pki/etcd/server.crt \
--key=/etc/kubernetes/pki/etcd/server.key \
snapshot save /opt/snapshot-pre-boot.db  #file location

2. Check the snapshot status command.

$ etcdctl \
     snapshot status snapshot.db

3. Restore the cluster from this backup later point in time. Follow steps below.

   • stop kube-apiserver and run the restore command.

   •       $ systemctl stop kube-apiserver
           $ etcdctl \
             snapshot restore snapshot.db
             --data-dir /var/lib/etcd-from-backup  # it initializes new cluster configuration with data directory

           $ etcd.service
           $ systemctl deamon-reload
           $ systemctl restart etcd
           $ systemctl start kube-apiserver.


       #Restore snapshot example
       etcdutl snapshot restore /opt/snapshot-pre-boot.db --data-dir /var/lib/etcd-from-backup
       #example output
       etcdutl snapshot restore /opt/snapshot-pre-boot.db --data-dir /var/lib/etcd-from-backup
       2025-04-24T09:38:07Z    info    snapshot/v3_snapshot.go:265     restoring snapshot      {"path": "/opt/snapshot-pre-boot.db", "wal-dir": "/var/lib/etcd-from-backup/member/wal", "data-dir": "/var/lib/etcd-from-backup", "snap-dir": "/var/lib/etcd-from-backup/member/snap", "initial-memory-map-size": 10737418240}
       2025-04-24T09:38:07Z    info    membership/store.go:141 Trimming membership information from the backend...
       2025-04-24T09:38:07Z    info    membership/cluster.go:421       added member    {"cluster-id": "cdf818194e3a8c32", "local-member-id": "0", "added-peer-id": "8e9e05c52164694d", "added-peer-peer-urls": ["http://localhost:2380"]}
       2025-04-24T09:38:07Z    info    snapshot/v3_snapshot.go:293     restored snapshot       {"path": "/opt/snapshot-pre-boot.db", "wal-dir": "/var/lib/etcd-from-backup/member/wal", "data-dir": "/var/lib/etcd-from-backup", "snap-dir": "/var/lib/etcd-from-backup/member/snap", "initial-memory-map-size": 10737418240}


     4. Update the newly restored directory path in file /etc/kubernetes/manifests/etcd.yaml as the host path.

          ...
           volumes:
           - hostPath:
               path: /var/lib/etcd-from-backup      # Newly restored backup directory
               type: DirectoryOrCreate
             name: etcd-data


5. ETCD pod is automatically re-created, as this is a static pod placed under the /etc/kubernetes/manifests directory. Watch logs.

    $ watch crictl ps

7. Once the updated etcd is up, check pods, deployments.

    kubectl get deployments, services

Note: So far, we have seen backup using etcd and clearing the kubeapi-server.

• in managed Kubernetes clusters like AKS, EKS, we won’t have access to etcd. In this case, backup using clearing the kube-apiserver is a better approach.
